F-10 fill weighing controller

F-10 fill weighing controller

F-10 fill weighing controller

The Flintec’s FT-10 Fill Weight Controller is an extremely precise and versatile weight indicator designed to use for a wide variety of weighing applications such as filling and dispensing. The FT-10 Fill Weight Controller automates the whole process whether it is a filling or dispensing of solid, liquid or gas.It is perfectly suitable for all types of process control systems and weighing applications because of its variety of selectable scale functions and industrial communication interfaces.This device is approved by Measures for use in Accuracy Class III applications with up to 10,000 intervals according to OIML R76and also approved by European Notified Body of Weights.It has a large 6 digit LED display (red 13,5 mm) with weight statusgives good readability. It also comes with options of Ethernet TCP/IP, Profibus DP, Profinet and can open

Functional Features

  • High internal resolution, display up to 9,99,999 counts
  • EU Type approved for 10 000 intervals
  • 3 point calibration
  • Electronic calibration (eCal)
  • Display in lb. or kg
  • Serial Interface RS232C, RS485
  • 4 opto-isolated digital inputs and 5 outputs (Relay contacts 250VAC or 30VDC)
  • Approved sensitivity 0.4 µV/e
  • Pre-configured applications for dispending tasks/typical filling
  • Up to 1600 conversion/second
