Type Flint weigh II PC based weighing systems:
The W&M approved FlintWeigh Scale Interface is a key element to integrate a Weighing System into your PC. Scales with RC3D Digital Load Cells and FlintWeigh PC Weighing System do not need any external weight display.The load cells are connected through RS485/USB- Converter straight to the PC.
The Flintweigh-Software for the computer is an OCX-Module with an Active-X-Control Interface. The approved Weight Display on the PC Monitor displays the accurate weight. An approved Alibi Memory is saved on the hard disk.A remote display and traffic light/barriers can be connected. We can connect 2 scales with functions Scale 1 / Scale 2 / Scale 1+2.
After sales services like set-up and calibration services are extremely easy with all required information on the monitor.The Flintec supply integratesthe FlintWeigh Scale Interface (Converter RS485/USB), FlintWeigh Basic Weighbridge application softwareand certified FlintWeigh PC software.
- Single or multi range/interval
- EU Type certified for 10 000 intervals
- Weight display on PC monitor certified
- Digital I/O for traffic lights and barrier
- RC3D connection
- Approved alibi memory on PC hard disk
- Interface for remote display
