Type LAC 65.1 Analogue Amplifier

Type LAC 65.1 Analogue Amplifier

Type LAC 65.1 Analogue Amplifier

The Analogue Amplifier LAC 65.1 by FlinTec is a universal amplifier for static/semi-static straining gauge applications. Settings for gain and zero and filtering are processed by DIP-switches. Moreover, fine trimming for gain and zero by potentiometers. Two analogue outputs are offered: current output (0/4 … 20 mA) and voltage output (±10 V)). It also features excess control, status signal by 2 LED’s and cable failure detection.

Functional Features

  • Load cells excitation of 2.5 V AC, 425 Hz up to 8 load cells 350 O
  • Two analogue outputs 0/4 … 20 mA and ±10 V
  • Input filtering 0.5. 32 Hz
  • Zero/gain regulation by DIP switches and fine trimming potentiometer
  • Extremely stable zero point
  • Power supply 12 … 24 V DC
  • 6 Wire load cells connectivity
  • Overflow control, LED display
  • Cable failure detection
  • DIN-rail mounting
