Type Lac 74.1 Analogue amplifier
TheFlintec’s Type LAC 74.1 Analogue Amplifier is a universal amplifier is designed for semi-static or static weighing applications. It has DIP switch settings gain; zero and filtering with Fine adjustment for gain and zero by 20 turn potentiometer. It is short-circuit proof and available with analogue output.
Voltage 0 … 10 V or
Current 0 … 20 mA or 4 … 20 mA
It features safety circuit with logic output and normally closed OC which opens in any case of error with LED display which shows:
Load cell cable failure
The current or voltage output is out of range
Power fail
Functional Features
6 Wire load cell connection
Load cell excitation 10 V DC for up to 4 load cells 350 O
Analogue output 0/4 … 20 mA or 0 … 10 V selectable
Gain/Zero adjustment through DIP switches and fine trimming potentiometer
Input filtering 0.33 … 33 Hz
Safety circuit with logic output including LED display
DIN-rail mounting
Power supply 12 … 24 V DC or 12 … 18 V AC
